40/50m Fog Cannon
Share to
- 产品描述
-
40-meter and 50-meter fog cannon machines are advanced dust suppression and environmental management systems designed to tackle airborne particles across a diverse range of industrial and commercial settings. These robust units are engineered to project a fine mist over impressive distances, effectively coagulating and settling dust particles from the air. Their core advantages lie in their stringent manufacturing processes, exceptional versatility in application, and the superior fineness of the water fog they produce.
A cornerstone of these fog cannons' reliability is their rigorous manufacturing craftsmanship. Constructed from high-grade, anti-corrosion materials such as stainless steel and reinforced alloys, these machines are built to endure harsh operating conditions, including exposure to abrasive dust and variable weather. Every component, from the high-power fan blades to the precision nozzles and the high-pressure pump system, undergoes stringent quality control and performance testing. This ensures operational durability, low maintenance requirements, and long-term performance stability, providing a dependable solution for continuous industrial use.
The wide spectrum of use cases for both the 40m and 50m models makes them an invaluable asset for numerous sectors. The 50m unit, with its extended range, is ideally deployed in large-scale open-air operations such as mining extraction sites, bulk material handling yards, demolition sites, and major construction projects. The 40m model offers agile and efficient dust control for moderately sized areas like shipping ports, waste transfer stations, agricultural processing facilities, and urban construction zones. This versatility allows a single machine to solve dust problems in environments ranging from quarries to public event venues.
Furthermore, the effectiveness of these cannons is largely due to the exceptionally fine water mist they generate. Utilizing high-pressure pump systems and specially engineered nozzles, they atomize water into microscopic droplets. This fine mist creates a maximum surface area for capturing PM10 and PM2.5 dust particles, mimicking the natural process of rainfall. This high efficiency ensures optimal dust suppression with minimal water consumption, preventing excessive moisture runoff and avoiding the creation of sludge or mud on the ground, which can disrupt operations.
In conclusion, whether opting for the 40m or the 50m model, these fog cannon machines represent a fusion of robust engineering, operational adaptability, and superior atomization technology. They provide an environmentally friendly and highly effective solution for companies seeking to enhance air quality, comply with environmental regulations, and ensure a safer, healthier atmosphere for workers and surrounding communities.
Product parameters
40m appearance 50m appearance
Packing size:1850*1650*1700mm
Gross Wight: 580kgs
5.2 CBMPacking size :1950*1750*1800mm
Gross Wight:650kgs
6.2 CBMBLUE OCEAN 40m Fog Cannon Specification Sheet Model LH-40 Spraying distance 40-45m windless condition Total power 11.8 kw Air volume 480 m3/min Fan power 7.5 kw Air pressure 700pa Water pump power 4 kw Protection level Above IP55 Pitch angle -10～45° or
customizedUsing ambient temperature -30～+50 °C Water Spray flow 2.5 m3/h Control method Manual/Remote control Horizontal rotation angle 320°/360° Control distance ≤ 100m Water pump pressure 2.0 ~3.0 Mpa Nozzle number 23 (can be customized) Mist particle size 20-300um(adjustable) Maximum coverage area 5000㎡ Water hose DN32 External water inlet joint DN25 wire connector Nozzle material Stainless steel Work way Remote/manual Voltage 380V Working frequency 50Hz BLUE OCEAN 50m Fog Cannon Specification Sheet Model LH-50 Spraying distance 50 m windless condition Total power 16.8 kw Air volume 530 m3/min Fan power 11 kw Air pressure 700pa Water pump power 5.5 kw Protection level Above IP55 Pitch angle -10～45° or
customizedUsing ambient temperature -30～+50 °C Water Spray flow 4 m3/h Control method Manual/Remote control Horizontal rotation angle ±140° Control distance ≤ 100m Water pump pressure 2.0 ~3.0 Mpa Nozzle number 23 (can be customized) Mist particle size 20-300um(adjustable) Maximum coverage area 5000㎡ Water hose DN32 External water inlet joint DN25 wire connector Nozzle material Stainless steel Work way Remote/manual Voltage 380V Working frequency 50Hz
